Product Features
• Embedded high performance CPU, support camera tracking functi on
• High effect circuit ensure that anti-interface function
• With USB recording in WAV format
• With 4 chanels input, each chanel supports 30 units. Main contr oller has cascading function, maximum 5 system
can be connected. 600 units maximum
• With S-video and 5 pins connector, to connect simple camera or HD camera, including SONY EVI, EV I HD, PELCO p/D, BRC300 protocol
• Built-in 6 in 2 out camera device, maximum 6 simple camears c an be connected
• With RS-232 connect for centrak controller
• System can be set in main contr oller or via computer
• Meeting mode includes FIFO, LIFO, FREE, CHAIRMAN, AUTO, etc.
• TIme off, auto off and voice control can be set
Specifications
Power supply : AC110V-220V/50Hz
Frequency response : 20Hz-20kHz
S/N ratio : >96dBA
TH.D. : <0.05%
Recording connector : USB
Input connector : DIN-8 x 4
Central controller connector : USBx1/RJ45x1
Audio input : RCAx2 6.3mm x1 (alarm device)
Audio output : RCAx2 6.3mm x1 XLR x1
