Benefits
- Contemporary design fits in everywhere
- Fan-less operation guarantees silence
- Energy-efficient
- Plug-and-play approach
- Easy browser-based configuration
- Effortless meeting recording via external USB connection
- Camera control integration capabilities
Features
- Touch sensor button technology
- Digital signal processing
- Integrated web server
- Integrated Recording (on USB storage device: not included)
- Selectable voice activation (VOX)
- Fail-safe redundancy technology (patent pending)
- Default digital acoustic feedback reduction
- For systems up to 50 units
- Controller/peripheral function to expand the system
- Menus and integrated LCD
- System volume
- On/Off button
Connectivity
- Balanced XLR input
- 1 Unbalanced RCA input
- 2 Unbalanced RCA outputs
- 4 Bus connections (4 branches or 2 loops)
- LAN connection
- 2 USB connections
- 1 Lockable Power connection
Specifications
| Mechanical | |
| Material | PC/ABS |
| Color | Black |
| Size (mm) Size packed (mm) | 300 (w) × 135 (h) × 50 (d) 345 (w) × 250 (h) × 155 (d) |
| Weight (g) Weight packed (g) | 1300 2600 (including D-Cerno PS, cable) |
| Microphone length (mm) | 300 |
| Electrical | |
| Power Supply input | 100-240 VAC 50-60 Hz, 2,5 A |
| Power supply output to power units | 48 VDC, 3.35 A, Max 160 W |
| Audio quality | 16 bit digital |
| Power consumption | Active 4 W Standby 0.7 W |
| Volume control | 0 dB to -72 dB + “OFF” |
| AUX 1 IN XLR balanced | |
| Input impedance | ≥ 7 kΩ (asymm.) |
| AUX 2 IN RCA unbalanced | |
| Input impedance | ≥ 20 kΩ (asymm.) |
| Input gain adjustment | +24 dB to -51 dB + “OFF” |
| AUX OUT 1,2 RCA unbalanced | |
| Max. output level | 0 dBV = -10 dBFS |
| Output impedance | ≤ 600Ω |
| Output gain adjustment | +24 dB to -51 dB + “OFF” |
| Headphone | |
| Load impedance | 16-150 Ω |
| Output power Max | 70 mW 32 Ω |
| Volume control | 0 dB to -72 dB + “OFF” |
